Photovoltaic Cable

As the professional manufacturer, we would like to provide you Paidu Photovoltaic Cable. Photovoltaic (PV) cables, also known as solar cables, are specialized cables used in photovoltaic systems to connect solar panels, inverters, charge controllers, and other components. These cables are designed to safely transmit direct current (DC) power generated by solar panels to the rest of the PV system or the electrical grid. Here are some key features and characteristics of photovoltaic cables:

Conductor Material: Photovoltaic cables typically feature tinned copper conductors due to copper's excellent conductivity and resistance to corrosion. Tinning the copper conductors enhances their durability and performance, particularly in outdoor environments.

Insulation: The conductors of photovoltaic cables are insulated with materials such as XLPE (Cross-linked Polyethylene) or PVC (Polyvinyl Chloride). The insulation provides electrical protection, preventing short circuits and electrical leaks, and ensures the safety and reliability of the PV system.

UV Resistance: Photovoltaic cables are exposed to sunlight in outdoor installations. Therefore, the insulation of photovoltaic cables is designed to be UV resistant to withstand prolonged exposure to sunlight without degradation. UV-resistant insulation helps maintain the integrity and longevity of the cable over its operational lifespan.

Temperature Rating: Photovoltaic cables are designed to withstand a wide range of temperatures, including both high and low temperatures commonly encountered in solar installations. The insulation and sheathing materials used in these cables are selected to ensure optimal performance under varying temperature conditions.

Flexibility: Flexibility is a crucial characteristic of photovoltaic cables, allowing for easy installation and routing around obstacles or through conduits. Flexible cables are also less prone to damage from bending and twisting during installation.

Water and Moisture Resistance: PV installations are subject to exposure to moisture and environmental elements. Therefore, photovoltaic cables are designed to be water-resistant and capable of withstanding outdoor conditions without compromising performance or safety.

Compliance: Photovoltaic cables must comply with relevant industry standards and regulations, such as UL (Underwriters Laboratories) standards, TÜV (Technischer Überwachungsverein) standards, and NEC (National Electrical Code) requirements. Compliance ensures that the cables meet specific safety and performance criteria for use in PV systems.

Connector Compatibility: Photovoltaic cables often come with connectors that are compatible with standard PV system components, facilitating easy and secure connections between solar panels, inverters, and other devices.
